Wire diameter:2.5-6.0mm
Maximum take-up speed:DV 120
Drum diameter:600/800mm
Maximum weight:2500 KG
Pay-off Machine is used in paying out the wires to the related machine. Take-up Machine is used in taking up the wires from the related machine into Spool or Coil. They are usually used with Drawing machine, Stranding machine, Wrapping machine, Rewinding machine, Pickling Line etc..
| NO | Item | Technical parameter |
| 1 | Wire diameter | 2.5-6.0mm |
| 2 | Maximum take-up speed | DV 120 |
| 3 | Drum diameter | 600/800mm |
| 4 | Maximum weight | 2500 KG |
Bear the weight of 2.5 tons wire rod, pay off the wire continuously, involve the button of start, stop,emergency stop.
We can put the line machine design and manufacture according to different types of customer requirements
