Pickling Line - Pickling Line

Appliaction:

Pickling is a metal surface treatment used to remove impurities, such as stains, inorganic contaminants, rust or scale from ferrous metals, copper, precious metals and aluminum alloys.

A solution called pickle liquor, which contains strong acids, is used to remove the surface impurities. It is commonly used to descale or clean steel in various steelmaking processes.

1. Hot water(Degreasing) tank&Charge Conveyor → 2. Pickling tank →  3. Coil Rotation Device → 4. High Pressure Spray System → 5. Washer Tank → 6. Phosphating Tank → 7. Rinse Tank → 8. Neutralization Tank → 9. Soap Tank → 10. Lime Tank → 11. Dryer → 12. Discharge Conveyor → 13. Storage tanks for HCL- Fresh acid → 14. Storage Pit for HCL- Waste acid → 15. Belt Press → 16. Sedimentation Tank → 17. Dosing Tank for Phosphating → 18. Scrubber System → 19. Automatic Transport Unit → 20. Support for Transport Unit → 21. Storage tanks for Soap- Waste → 22. Condensate Collecting Tank → 23. Waste Water Tank → 24. Room for Control Panel
