Applicable to the production of a variety of nails. Ordinary nails, gas row nails, rivets, etc. (different equipment)
| Model | Z94-1 | Z94-2 | Z94-3 | Z94-4 | Z94-5 |
| Dimensions of machine(mm) | 1440*1040*1270 | 1670*1240*1380 | 1830*1300*1470 | 2130*1560*1580 | 2500*1600*1700 |
| Weight(kg) | 1200 | 1400 | 1700 | 2000 | 2500 |
| Type of nails | normal | ||||
| Diameter of Nail | 0.9-1.6 | 1.2-2.8 | 1.8-3.4 | 2.8-4.5 | 3.7-5.5 |
| Length of Nail | 9-25mm | 16-50mm | 30-75mm | 50-100mm | 80-150mm |
| (0.35-0.98)’’ | (0.93-1.97)’’ | (1.18-2.95)’’ | (1.97-3.94)’’ | (3.15-5.91)’’ | |
| Capacity(pcs) | 450 | 350 | 320 | 280 | 200 |
